Item |
Unit |
YTR 230D |
YTR 300D |
YTR 360C |
YTR 360D |
YTR 360H |
|
|
Key Parameters |
Max. Drilling Diameter |
mm |
2000 |
2500 |
2500 |
2500 |
2500 |
|
Standard Drilling Depth |
m |
52/68 |
52/76 |
66/100 |
66/100 |
66/100 |
|
|
Max. Drilling Depth |
m |
75 |
60/90 |
70/106 |
66/100 |
70/106 |
|
|
Engine |
Engine Model |
|
DC09 |
DC13 |
C13ACER |
DC13 076A |
DC13 076A |
|
Engine Manufacturer |
|
SCANIA |
SCANIA |
CAT |
SCANIA |
SCANIA |
|
|
Rated Power |
kW |
214 |
257 |
328 |
294 |
294 |
|
|
Rotary Drive |
Max. Output Torque |
kN.m |
246 |
318 |
360 |
360 |
360 |
|
Revolution |
r/min |
6~30 |
5~25 |
5~23 |
5~23 |
5~23 |
|
|
Gears |
|
Two Speed |
Two Speed |
Two Speed |
Two Speed |
Two Speed |
|
|
Crowd Cylinder |
Max. Push Force |
kN |
215 |
215 |
300 |
300 |
300 |
|
Max. Lift Force |
kN |
230 |
230 |
300 |
300 |
300 |
|
|
Push Stroke |
mm |
5300 |
5300 |
6000 |
6000 |
6000 |
|
|
Main Winch |
Lift Force |
kN |
240 |
300 |
350 |
350 |
350 |
|
Max. Descending Speed |
m/min |
65 |
69 |
63 |
63 |
63 |
|
|
Winch Location |
|
Rear |
Rear |
Rear |
Rear |
Rear |
|
|
Wire Rope Diameter |
mm |
28 |
36 |
36 |
36 |
36 |
|
|
Mast |
Front Inclination Angle |
° |
3 |
3 |
|
|
|
|
Behind Inclination Angle |
° |
|
|
10 |
10 |
10 |
|
|
Left & Right Inclination Angle |
° |
3.5 |
3.5 |
3.5 |
3.5 |
3.5 |
|
|
Chassis |
Track Shoe Width |
mm |
800 |
800 |
800 |
800 |
800 |
|
Traction Force |
kN |
410 |
720 |
720 |
720 |
720 |
|
|
Track Length |
mm |
4950 |
4950 |
5000 |
5160 |
5160 |
|
|
Dimension |
Working Condition Width |
mm |
4300 |
4700 |
4400 |
4800 |
4800 |
|
Working Condition Height |
mm |
22420 |
23320 |
27480 |
25830 |
27520 |
|
|
Transportation Condition Length |
mm |
16070 |
17870 |
18500 |
19535 |
17880 |
|
|
Transportation Condition Height |
mm |
3590 |
3860 |
3950 |
3890 |
3340 |
|
|
Transportation Condition Width |
mm |
3300 |
3400 |
3000 |
3400 |
3400 |
|
|
Weight |
Working Condition |
t |
76.8 |
97 |
112 |
115 |
113 |
|
Transportation Condition |
t |
65 |
79 |
74 |
96 |
74 |
|
|
Kelly Bar |
Standard Kelly Bar Specification |
|
Interlock Type, φ440-4X14.5m-200B (Drilling Depth 52m) |
Interlock Type, φ508-4X14.5m-200B (Drilling Depth 52m) |
Interlock Type, φ530-4X18m-200B (Drilling Depth 66m) |
Interlock Type, φ530-4X18m-200B (Drilling Depth 66m) |
Interlock Type, φ530-4X18m-200B (Drilling Depth 66m) |
|
Longest Kelly Bar |
|
Friction Type, φ440-5X15m-200B (Drilling Depth 68m) |
Friction Type, φ508-6X16.5m-200B (Drilling Depth 90m) |
Friction Type, φ530-6X19m-200B (Drilling Depth 106m) |
Friction Type, φ530-6X18m-200B (Drilling Depth 100m) |
Friction Type, φ530-6X19m-200B (Drilling Depth 106m) |
|
|
Standard Kelly Bar Transport Dimension |
mm |
15950 x 650 x 650 |
15980 x 700 x 700 |
19500 x 860 x 860 |
19500 x 860 x 860 |
19500 x 860 x 860 |
|
|
Longest Kelly Bar Transport Dimension |
mm |
16450 x 650 x 650 |
17980 x 700 x 700 |
20500 x 860 x 860 |
19500 x 860 x 860 |
20500 x 860 x 860 |
|
